OKM Gepard GPR 3D
W-9 and vendor pack with every quote
Shipped direct from the manufacturer
Two 1.50-kilogram antennas on adjustable shafts, walked across the ground to find pipelines, cavities, tunnels and voids. OKM's own manual says real depth depends on soil, not a number on a spec sheet.
01
OKM's own manual says real depth depends on soil, and the antennas only work if you carry them right
Ground penetrating radar sends a signal into the earth and reads the echo that bounces back, tuned here to find pipelines, cavities, voids and faults. Two antennas do the work, red-marked to transmit, silver-marked to receive, on their own telescopic shafts: 1.50 kilograms each antenna, 0.80 kilograms each shaft. OKM's field guidance calls for a steady antenna height, about 10 centimeters where terrain allows, since changing height mid-scan introduces error. Before every scan the operator sets a soil type in the app, and OKM's manual is direct about why: depth reads close to actual only when that setting is right. Its own reference table on ground materials shows signal loss swinging by roughly four orders of magnitude between dry rock and seawater. The unit is IP20, not waterproof.
A real bunker search, not a demo reel
OKM's own three-part field series, embedded first in the video carousel on the manufacturer's Gepard GPR 3D product page.
02
OKM names its own scan modes two different ways, and neither one is picked as correct here
Starting a scan means two choices. Scan type is 2D, a single line to pre-check an area for large anomalies, or 3D, multiple parallel lines building a full-area data set viewable afterward in either form. Scan pattern is Parallel, every line starting from the same side with a walk-back before the next, or Zig-Zag, running in both directions with no walk-back. OKM says Parallel suits uneven or sloped ground and gives experienced users their best graphics; Zig-Zag suits a fast first pass. None of that workflow matches OKM's own product page, whose feature list reads "Operating modes: 3D Ground Scan, 2D Radargram." The manual's software walkthrough instead uses "2D Scan" and "3D Scan," each run as Parallel or Zig-Zag. Two namings, both from OKM directly, and we are not picking a winner.
03
Two antennas connect by color, and both send or read a 60 to 300 megahertz signal
The transmitting antenna carries a red-marked connector and sends the radar signal, adjustable across 60 to 300 megahertz through its telescopic elements, into the ground. The receiving antenna carries a silver-marked connector and collects the echo. Both are triangular, unshielded, 1010 by 330 by 50 millimeters, and weigh 1.50 kilograms each. A telescopic shaft mounts each antenna to the control unit, adjusts from 590 to 1630 millimeters for the operator's height, and houses the rechargeable battery, 7.26 volts, 2600 milliamp hours, that powers the control unit. The control unit itself sets four levels of send and receive timing, runs 9 complete measurement cycles a second, and records 512 samples per cycle.
04
The tablet connects by USB-C cable, and OKM's manual wants that cable in place before every scan
OKM's current product page and manual agree, in near-identical wording, that the tablet talks to the control unit over a physical USB-C cable, and the manual says to connect the two before every scan since an overlong cable can interfere with the measurement. Two of the three dealer pages we checked describe this as WiFi instead. This page follows OKM's current pages, and the WiFi description looks like it carries over from an earlier Gepard generation, unconfirmed with OKM directly. The tablet runs the Gepard GPR 3D Android app, activated once by QR code or a manual code. Data exports as PDF, PNG, CSV or DZT. GPS is optional per scan, receive-only, and places a scan on a map rather than touching the antenna signal. Analysis runs on OKM Visualizer 3D Studio, Professional Edition, on the included USB flash drive.
05
The control unit runs about 4 hours on a charge, and OKM never publishes how long it takes to refill
Each telescopic shaft's own battery, 7.26 volts and 2600 milliamp hours, powers the control unit for about 4 hours per charge. OKM does not publish a cycle count or a charging time anywhere we checked, including the full manual, which describes only a charging LED that switches off once full. The control unit runs -20 to 55 degrees Celsius and stores at -25 to 60, per OKM's manual and its live product page, which agree with each other. Humidity is rated 5 to 70 percent. A built-in anti-tampering module destroys the unit if opened improperly, so there is nothing inside to service.
06
OKM's manual carries an unprompted warning: if a buried find looks like ordnance, leave it and call the police
Unexploded ordnance and war-era relics remain buried across much of the world, and OKM's manual raises this unprompted: note reddish ground color as a possible rust indicator, treat curved or round objects, buttons, rings, ammunition or shells as alarm signs, and do not dig, handle or move anything that fits that description, since old explosives can form residue that detonates on contact; report finds to the police instead. OKM states the radar poses no ordinary health hazard under normal use, citing the low power of its signal. The transmitting system is unshielded, and OKM's manual states plainly it is not approved for use in the European Union, with an instruction to check local regulations; that notice does not appear on OKM's own product page or FAQ. Keep the unit 50 meters from large motors or unshielded loudspeakers, and keep metal, phones, keys or jewelry off the operator, since these can distort scan data. Cold-to-warm condensation and direct mains power both carry their own manual warnings; only OKM's own charger should ever connect to the unit.
07 FOR UNIVERSITIES, COLLEGES AND GOVERNMENT AGENCIES
My Surveying Direct ships the Gepard GPR 3D direct from OKM and takes purchase orders from institutions
My Surveying Direct is an authorized OKM dealer. Purchase orders are accepted from universities, colleges and government agencies. OKM's own product page and its own current manual disagree on the full packing list: the product page names 11 items, including Bluetooth headphones and a software USB flash drive, while the manual's own scope-of-delivery chapter names 8 and includes neither of those nor the printed quick start guide. We have not been able to resolve which list is current, so call and we will confirm the exact contents against your order before you buy. Reach us at +1 888 850 6533, Monday to Friday, 9 to 5 Mountain Time.
Checkout above. Financing available with Affirm.
Institutions only: universities, colleges and government agencies.
Attached automatically.
Send the certificate once, we hold it on file.
On request, for committee approval.
One person, from quote to delivery.
REFERENCE
Specifications
Control unit
| Model | Gepard GPR 3D, Model GPR-D01 per the manufacturer's June 2026 user manual |
| Dimensions (H x W x D) | 450 x 260 x 130 mm |
| Weight | Approx. 1.60 kg |
| Input (max.) | 8.4 V DC, 1.0 A |
| Operating temperature | –20°C to +55°C |
| Storage temperature | –25°C to +60°C, per the manufacturer's manual and its live product page, which agree with each other |
| Air humidity | 5% to 70% |
| Waterproof | No |
| Protection type | IP 20 |
| Operating time | Approx. 4 hours |
| Data transmission (control unit to tablet) | USB-C cable. The control unit and tablet must be physically connected with the included USB-C cable before a scan; OKM's manual warns that overlong cables can interfere with the measurement data. Two of the three dealer pages checked instead describe this as wireless "WiFi, 2.4 GHz" transfer. OKM's current product page and its current manual both say USB-C cable in identical wording; the WiFi description appears to be inherited from an older Gepard GPR generation |
| Transmission frequency range | 60 MHz to 300 MHz, multiple frequencies via the antennas' telescopic elements |
| Timing/sampling adjustments (send/receive) | 4 levels |
| Complete cycle measurements | 9 per second |
| Samples | 512 |
| Charging time | Not published by OKM on the product page, specification table or the 2026 manual, which describes only a charging LED that switches off once fully charged, with no hours figure |
Antenna and radar system
| How it works | OKM's own explanation: the RADAR (Radio Detection And Ranging) sends a signal into the ground and awaits the reflection, or "echo", of the signal to detect sub-surface anomalies, including metallic objects and non-metallic features like strata formations, cavities, voids and faults |
| What GPR means, per OKM's own FAQ | "GPR has two different meanings: On the one hand, it describes the Geophysical Phase Reader technology, on which our ground scanners are based. On the other hand it is a common abbreviation for Ground Penetrating Radar" |
| Transmitting antenna | Triangular, unshielded, red-marked connector. Generates the 60–300 MHz signal sent into the ground |
| Receiving antenna | Triangular, unshielded, silver-marked connector. Collects echoes and reflections to calculate potential anomalies |
| Triangular antenna dimensions (each) | 1010 x 330 x 50 mm |
| Triangular antenna weight (each) | 1.50 kg |
| Antenna operating/storage temperature | –20°C to +55°C operating; –25°C to +60°C storage; IP20, not waterproof |
| Telescopic shaft | Mounts each antenna to the control unit and houses a rechargeable battery (7.26 V, 2600 mAh) that powers the control unit. Two are required, one per antenna |
| Telescopic shaft dimensions | 70 x 60 x (590–1630) mm, adjustable for the user's height |
| Telescopic shaft weight (each) | 0.80 kg |
| Antenna spacing during a scan | OKM recommends holding both antennas at a consistent height above the ground throughout a measurement, about 10 cm (0.4 in) where the terrain allows, or up to 30 cm (1 ft) over obstacles; changing height mid-scan is called out as a source of measurement error |
Delivery scope, per the manufacturer's current product page
| Control unit | 1x |
| Android tablet | 1x |
| Telescopic shaft | 2x |
| Sending antenna for Gepard GPR 3D | 1x |
| Receiving antenna for Gepard GPR 3D | 1x |
| USB flash drive | 1x, with OKM Visualizer 3D Studio Professional Edition |
| Bluetooth headphones | 1x, including charging cable |
| Charger | 1x, with charging cable |
| Travel adapter set | 1x |
| Protector case | 1x, waterproof and shock-resistant |
| Quick start guide | 1x |
| Optional | Pre-configured Windows notebook, offered as an add-on rather than a standard inclusion |
| Contradiction | OKM's own June 2026 user manual, Chapter 3 "Scope of Delivery", lists only 8 items for this same product: control unit, charging adapter with power supply and travel adapter, Android tablet, USB-C cable, protector case, 2x telescopic shaft, transmitting antenna, receiving antenna. It does not list Bluetooth headphones, the USB flash drive/software, or a quick start guide at all. Not resolved. Call +1 888 850 6533, Monday to Friday, 9 to 5 Mountain Time, and we will confirm your exact packing list before you buy |
Operating modes, per the 2026 manual's own software walkthrough
| New scan: 2D | A single straight scan line, used to pre-check an area for large anomalies like pipelines or tunnels |
| New scan: 3D | Multiple parallel scan lines walked side by side to build a full-area 3D data set, viewable afterward in either 2D or 3D |
| Scan pattern: Parallel | Every scan line starts from the same side of the area; the user walks back to the start without recording between lines. OKM's own field-procedure advice: experienced users get their best graphics in Parallel mode, and it is preferred on uneven or sloped terrain |
| Scan pattern: Zig-Zag | Adjacent scan lines start on opposite sides of the area, recording in both directions without walking back; OKM notes experienced users often use Zig-Zag for a fast initial pass |
| Soil type and depth setting | Before a scan, the operator selects a soil type and a maximum depth (Low, Medium, High, Maximum) in the app; OKM states selecting the correct soil type is what makes the depth reading close to actual, and recommends calibrating soil type by scanning over a target buried at a known depth |
| Post-scan filtering | Bias, Extraction, Interpolation and Envelope filters can be applied after a scan to reduce noise and sharpen potential targets; OKM's manual describes these as for professional users and warns that changing them can result in "wrong data display" |
| Note on naming | OKM's own live product page states, in its top-of-page feature list: "Operating modes: 3D Ground Scan, 2D Radargram". This conflicts with the 2026 manual's own software walkthrough, which instead documents "2D Scan" and "3D Scan" (each run as either a "Parallel" or "Zig-Zag" pattern) as the two modes offered when starting a new scan, with no "Ground Scan" or "Radargram" naming anywhere in that walkthrough. |
Software
| Data collection app | Gepard GPR 3D Android app, installed on the included Android tablet from Google Play, requires one-time activation (QR code or manual serial/activation code entry) |
| Analysis software | OKM Visualizer 3D Studio, Professional Edition per the product page's delivery scope; supplied on a USB flash drive |
| Export formats | PDF, PNG, CSV and DZT (a format common to general GPR software products) |
| GPS | Optional per scan; receive-only, does not transmit, available in most parts of the world per OKM. Used to place scans on a Google Map and to calculate field length/width automatically |
| App languages | Arabic, Bulgarian, German, Greek, English, Spanish, Persian, French, Italian, Russian, Chinese |
Safety and cautions, per OKM's own manual
| Regulatory notice, unshielded transmitter | "The Gepard GPR utilizes an unshielded transmitting system to be as portable as possible. It is not approved for the usage in the EU. Please check the local regulations of your country!" Present in identical wording in both the 2020 and 2026 editions of OKM's manual. Not found anywhere on OKM's live product page or FAQ, checked directly on both. This is a general-EU regulatory notice from the manufacturer about the unshielded RF transmitter; MYSD sells to US institutional buyers under US regulation and this notice was not tested against US rules |
| Possible health hazards | "If used properly this device normally does not pose any health hazards. According to current scientific knowledge, the high-frequency signals are not harmful to the human body on account of their very low power" |
| Anti-tampering | The control unit has a built-in anti-tampering module that destroys the unit if it is improperly opened; there are no end-user-serviceable parts inside |
| Surrounding area | Avoid strong magnetic fields; OKM recommends staying at least 50 m (150 ft) from large electric motors or unshielded loudspeakers. Metallic objects on the ground (cans, tin, nails, screws, debris) or on the operator's person (phones, keys, jewelry) can influence scan data; steel-toe boots are called out specifically |
| Condensation | Moving the unit from a cold place to a warmer one can cause condensation; OKM instructs waiting for it to evaporate before operating, since the unit is not weatherproof and condensation can destroy it |
| Voltage | Use only OKM-approved chargers, supplied with the unit. "Never connect or use a 110/230 Volt main AC power supply directly!" |
| Data safety | OKM lists four causes of data errors: exceeding the sender module's range, low power supply or battery charge, operating too close to interference-causing devices, and atmospheric conditions such as electrical storms or lightning |
| Danger of explosion during excavation | OKM's manual carries a dedicated warning, unprompted by any question, that unexploded ordnance and war-era relics remain buried across much of the world. It instructs the operator not to dig or handle a metallic signal impulsively: note reddish ground color as a rust indicator, treat curved or round objects, buttons, rings, ammunition or shells as alarm signs, leave such finds in place, not touch or take them, and report finds to police, since old explosives can form friction-sensitive crystalline residue that detonates if disturbed |
| Maintenance | Avoid penetrating water, heavy dirt/sand/dust, hard impacts or drops, strong magnetic fields, operating inside metal enclosures, and continued exposure to high heat. Clean with a dry, soft cloth only; transport in the supplied case |
Ordering
| Dealer status | Authorized OKM Dealer |
| Purchase orders | Accepted from universities, colleges and government agencies |
| Shipping | Shipped direct from the manufacturer |
| Speak to us | +1 888 850 6533, Monday to Friday, 9 to 5 Mountain Time |
