DJI Matrice 4TD Drone
W-9 and vendor pack with every quote
Shipped direct from the manufacturer
54 minutes, -20 °C to 50 °C, and a 6S battery with self-heating charging. The thermal detector is the same 640 × 512 as the Matrice 4T, and the arms are fixed, so it packs worse.
01
DJI rates this aircraft IP55, and rates the Matrice 4T we also sell as No Standard Protection Level
IP is the ingress protection scale for dust and water. DJI's FAQ answers the comparison itself, in five items. IP55 protection. A 54-minute maximum flight time. Greater payload capacity. Airborne relay. Arms that do not fold. The specification tables add more. Two decide most jobs. This aircraft operates from -20 °C to 50 °C where the 4T runs -10 °C to 40 °C. Its battery is 6S, six cells in series, at 149.9 Wh, against the 4T's 4S at 99.5 Wh. DJI claims the greater payload capacity without publishing a figure for it, so we quote none. Four of the five favor this aircraft. The fifth is the reason to think twice.
Built for the dock, flies without it
DJI Enterprise's launch film for DJI Dock 3 and the Matrice 4D Series.
02
The arms do not fold, and for a crew working out of a truck that is the argument for buying the 4T
DJI puts the aircraft at 377.7 × 416.2 × 212.5 mm without propellers, and that is the size it stays. The 4T folds. This does not. Every case, every locker and every back seat takes the full span on every job. One note worth having early: the visible gaps at each arm base are rotational dampers that cut vibration, not defects. Buy the Matrice 4T instead if the aircraft travels more than it flies, or if it lives in a pack between sites. Buy it too if your work is fair-weather and mild air, where the bulk buys you nothing. It earns its size in conditions the 4T carries no rating for.
03
IP55 is a laboratory figure that wears off, and DJI still tells you to stay out of moderate rain
DJI's own footnote: tested in controlled laboratory conditions, and the rating "is not permanently effective and may decrease due to product wear and tear". Its checklist before flight names the failure mode. Leave the cover off an unused port and the ingress protection performance is affected. The safety guidelines still call this good to moderate weather equipment, and rule out winds above 12 m/s, snow, moderate rain, fog, hail and lightning. The 12 m/s wind resistance figure covers operation as well as takeoff and landing. Do not power it on with water inside, which DJI says may cause permanent component damage. The wide, medium tele and tele cameras do support lens defogging. IP55 changes none of the rest.
04
The thermal detector is the same 640 × 512 as the 4T, and the measurement window is where the two differ
The sensor is an uncooled VOx microbolometer, an infrared detector, at 640 × 512 and 30 Hz. UHR Infrared Image mode, ultra-high resolution, outputs 1280 × 1024 with Night Scene off. The lens matches the 4T's too. The measurement window moved in both directions. High Gain reads -40 °C to 150 °C where the 4T reads -20 °C to 150 °C. Low Gain reads 0 °C to 500 °C where the 4T reads 0 °C to 550 °C. Colder at the bottom, 50 degrees short at the top. DJI's warning is blunt. Do not expose the infrared lenses to strong energy sources such as the sun, lava or a laser beam. The sensor may be burned permanently. No ceiling temperature for it appears on DJI's product page, specifications, FAQ or safety guidelines, so we name none. The gimbal, the powered camera mount, now tilts to +90° rather than +70°. Above +70° the body obstructs the wide, medium tele and thermal cameras, DJI warns.
05
The 54 minutes is a windless lab figure, and the battery underneath it is a different product
DJI measured it flying forward at a constant 12 m/s, windless, 20 m above sea level. Photo mode, Obstacle Avoidance Action off, run from 100% to 0%. Hovering in the same conditions gives 47 minutes. Plan for less than either. The pack is a Matrice 4D Series Battery, model BPX230-6768-22.14: Li-ion 6S, 149.9 Wh, 640 g, rated for 400 cycles. It supports low-temperature self-heating charging. The 4T's 4S pack is 99.5 Wh, rated for 200 cycles, with no self-heating. The two are not interchangeable, and this aircraft charges through its own 240 W hub rather than the 100 W hub the 4T and 4E use. Charge between 5 °C and 45 °C, and not straight after landing, because DJI says a hot pack can be seriously damaged.
06
You do not need a dock, and DJI publishes a separate manual for flying this aircraft on a controller
DJI's FAQ is direct: the 4D Series supports manual flight with DJI RC Plus 2 Enterprise, and DJI publishes a separate manual for it. Its controller table lists that controller against the 4TD, 4D, 4T and 4E. A controller bought for a Matrice 4T flies this one too. Two controllers at once are not supported. Transmission is O4+ Enterprise rather than the 4T's O4 Enterprise, though both publish 25 km maximum under FCC rules. DJI also gives the 4D Series airborne relay, where one drone flies high and relays the signal for another through mountainous terrain. Asked whether relay works when connected with DJI Dock 3, DJI answers currently no. Relay is a controller-flown capability.
07 FOR UNIVERSITIES, COLLEGES AND GOVERNMENT AGENCIES
How to buy it, starting with where it will fly and what your configuration includes
DJI's answer on using the Matrice 4D Series across countries or regions is a flat no. It says to confirm the applicable ones with your dealer before buying, so name the country when you call. DJI publishes no labeled packing diagram for the 4D Series on its product page, its specifications or its FAQ. The aircraft also sells in more than one configuration. We will not print box contents or accessory availability we cannot match to your order. The controller's own ingress rating is a separate figure from the aircraft's, and we quote none. The 4D Series is C2 and C6 certified by the European Union Aviation Safety Agency. My Surveying Direct is an authorized DJI Enterprise dealer, ships direct from the manufacturer, and takes purchase orders from universities, colleges and government agencies. Call +1 888 850 6533, Monday to Friday, 9 to 5 Mountain Time.
Checkout above. Financing available with Affirm.
Institutions only: universities, colleges and government agencies.
Attached automatically.
Send the certificate once, we hold it on file.
On request, for committee approval.
One person, from quote to delivery.
REFERENCE
Specifications
Aircraft
| Model designation | DJI's own safety documentation names the airframe M4D or M4TD. The Matrice 4TD is the thermal-camera variant |
| Weight | 1850 g, including the battery, propellers and a microSD card, excluding payload. Actual weight may vary with batch materials |
| Max takeoff weight | 2090 g |
| Dimensions | 377.7 × 416.2 × 212.5 mm (L×W×H), without propellers. DJI states the arms of the Matrice 4D Series do not fold, unlike the Matrice 4T and 4E; visible gaps at the arm base are rotational dampers that reduce vibration, not a defect |
| Max flight time | 54 minutes. Measured flying forward at a constant 12 m/s in a windless lab environment at 20 m above sea level, in photo mode with Obstacle Avoidance Action off, from 100% battery to 0% |
| Max hovering time | 47 minutes, measured hovering in a windless environment at 20 m above sea level from 100% to 0% battery |
| Max operating radius | 10 km, measured at approximately 25 °C with a 15% safe battery reserve, windless, round-trip flight speed of about 15 m/s and an 18-minute hover on site |
| Max flight distance | 43 km, flying at a constant 16 m/s in a windless environment at 20 m above sea level, from 100% battery to 0% |
| Max ascent and descent speed | Ascent: 6 m/s Normal Mode, 10 m/s Sport Mode. Descent: 6 m/s Normal Mode, 8 m/s Sport Mode |
| Max horizontal speed | Normal Mode with Obstacle Sensing enabled: 15 m/s forward, 12 m/s backward, 10 m/s sideways. Sport Mode: 21 m/s forward, 19 m/s backward, 15 m/s sideways. DJI: when used with DJI Dock, only Normal Mode is supported |
| Max wind resistance | 12 m/s during operation, and 12 m/s during takeoff and landing. The Matrice 4T's own specs page states its 12 m/s figure applies only during takeoff and landing, not in flight |
| Max altitude | 6500 m max takeoff altitude on the specs page; DJI's safety guidelines separately instruct: do not take off from an altitude more than 6,500 m (21,325 ft) above sea level |
| Operating temperature | -20 °C to 50 °C (-4 °F to 122 °F), confirmed identically in both the specs table and the safety guidelines PDF |
| GNSS | GPS + BeiDou + Galileo + QZSS + GLONASS; QZSS and GLONASS are supported only when the RTK module is enabled |
| Hovering accuracy | Vertical: ±0.1 m with vision positioning, ±0.5 m with GNSS, ±0.1 m with RTK. Horizontal: ±0.3 m with vision positioning, ±0.5 m with GNSS, ±0.1 m with RTK, in windless or breezy conditions |
| RTK positioning accuracy | RTK Fix status: 1 cm + 1 ppm horizontal, 1.5 cm + 1 ppm vertical |
| RTK module | Integrated on the aircraft |
| Beacon | Integrated on the aircraft. DJI's safety guidance: DO NOT point the beacon directly into eyes to avoid injury |
| Propellers and motors | 1364F foldable low-noise anti-ice propellers, motor model 2611 |
What the Matrice 4D Series has that the Matrice 4T and 4E do not
| DJI's own stated differences | Asked directly what differs between the Matrice 4D Series and the Matrice 4 Series (4T/4E), DJI's FAQ answers: 1. Supports IP55 protection rating. 2. Maximum flight time of 54 minutes. 3. Supports greater payload capacity. 4. Supports airborne relay, where one drone can fly high as a relay, addressing signal issues in mountainous terrain. 5. Arms of the Matrice 4D Series are not foldable |
| Ingress protection | Matrice 4TD: IP55, DJI's own term. Matrice 4T: No Standard Protection Level, DJI's own term. This is the largest weather-handling difference between the two aircraft |
| Payload capacity | DJI states the Matrice 4D Series supports greater payload capacity than the Matrice 4T/4E, but does not publish a numeric max payload figure for the 4D Series, unlike the Matrice 4T/4E's stated 200 g |
| Video transmission system | Matrice 4TD: DJI O4+ Enterprise. Matrice 4T: DJI O4 Enterprise, per its own specs page. Both are rated to the same 25 km (FCC) / 12 km (CE/SRRC/MIC) maximum transmission distance on their respective specs pages |
| Battery | Matrice 4TD uses the DJI Matrice 4D Series Battery (model BPX230-6768-22.14): 6768 mAh, 22.14 V, Li-ion 6S, 149.9 Wh, 640 g, rated for 400 cycles, and supports low-temperature self-heating charging. The Matrice 4T's Intelligent Flight Battery is 6741 mAh, 14.76 V, Li-ion 4S, 99.5 Wh, 401 g, rated for 200 cycles, and does not support self-heating. The two are different products and are not interchangeable |
| Airborne relay | DJI states the Matrice 4D Series supports airborne relay, letting one drone fly high to relay signal in mountainous terrain, and lists it among the five differences from the Matrice 4 Series. DJI's FAQ: "Do the DJI Matrice 4D Series drones support airborne relay when connected with DJI Dock 3? Currently no." DJI's product page ties the function to standalone operation with the DJI RC Plus 2 Enterprise remote controller |
| Certification | DJI: the Matrice 4D Series is C2 and C6 certified by the European Union Aviation Safety Agency (EASA). The Matrice 4T/4E's own FAQ states C2 certification only |
| Gimbal controllable tilt range | Matrice 4TD: -90° to +90°, though DJI notes that tilting between +70° and +90° obstructs the wide, medium tele and thermal cameras with the aircraft body. The Matrice 4T's own specs page publishes -90° to +70°, narrower |
| Lens defogging | DJI: the Matrice 4D and Matrice 4TD's wide-angle, medium tele and tele cameras all support lens defogging. |
Thermal camera, Matrice 4TD only
| Thermal sensor | Uncooled VOx Microbolometer, 640 × 512 native, 12 μm pixel pitch, 30 Hz frame rate. Same sensor type and native resolution as the Matrice 4T |
| UHR Infrared Image mode | 1280 × 1024 resolution when UHR Infrared Image mode is enabled and Night Scene mode is off, at 30 fps |
| Thermal lens | 45° ± 0.3° DFOV, 53 mm format equivalent, f/1.0, focus 5 m to infinity. Matches the Matrice 4T's thermal lens figures |
| Sensitivity (NETD) | ≤ 50 mK @ f/1.0 |
| Infrared wavelength | 8 to 14 μm |
| Temperature measurement range | High Gain: -40 °C to 150 °C (-40 °F to 320 °F). Low Gain: 0 °C to 500 °C (32 °F to 932 °F). Differs from the Matrice 4T's own published range: High Gain -20 °C to 150 °C, Low Gain 0 °C to 550 °C |
| Temperature measurement accuracy | High Gain: ±2 °C or ±2%, whichever is greater. Low Gain: ±5 °C or ±3%, whichever is greater. Matches the Matrice 4T's published accuracy |
| Sensor protection | DJI: "DO NOT expose the infrared camera lenses to strong sources of energy such as the sun, lava, or a laser beam. Otherwise, the camera sensor may be burned leading to permanent damage." |
| Digital zoom | 28× |
| Palette options | White Hot, Black Hot, Tint, Iron Red, Hot Iron, Arctic, Medical, Fulgurite, Rainbow 1, Rainbow 2 |
| Video and photo format | Video: MP4 (H.264/H.265), 640 × 512 @30fps normal, 1280 × 1024 @30fps in UHR mode. Photo: JPEG (8-bit) and R-JPEG (16-bit) |
Cameras and laser rangefinder
| Wide-angle camera (Matrice 4TD) | 1/1.3-inch CMOS, 48 MP effective, f/1.7, 24 mm format equivalent, 82° FOV, focus 1 m to infinity. DJI's own image-sensor table gives the Matrice 4D's wide camera as a different part: 4/3-inch CMOS, 20 MP effective. The two models do not share a wide camera |
| Medium tele camera | 1/1.3-inch CMOS, 48 MP effective, f/2.8, 70 mm format equivalent, 35° FOV, focus 3 m to infinity. Shared between the Matrice 4D and 4TD |
| Tele camera | 1/1.5-inch CMOS, 48 MP effective, f/2.8, 168 mm format equivalent, 15° FOV, focus 3 m to infinity, 16× digital zoom (112× hybrid zoom). Shared between the Matrice 4D and 4TD |
| Shutter | Matrice 4TD: 2 to 1/8000 s across all three cameras, no mechanical shutter. Matrice 4D's wide camera additionally has a mechanical shutter, 2 to 1/2000 s |
| Max photo size | Matrice 4TD: wide 8064 × 6048, medium tele 8064 × 6048, tele 8192 × 6144. Matrice 4D's wide camera differs: 5280 × 3956 |
| Photo format | Matrice 4TD: JPEG only, all three cameras. Matrice 4D: wide camera shoots JPEG and DNG RAW; medium tele and tele are JPEG only |
| Minimum photo interval | Matrice 4TD: 0.7 s. Matrice 4D: 0.5 s |
| ISO range, Night Scene mode | Matrice 4TD: wide and medium tele 100 to 409600, tele 100 to 819200. Matrice 4D: wide 100 to 204800, medium tele and tele 100 to 409600 |
| Video | H.264/H.265, 4K at 3840 × 2160 @30fps, FHD at 1920 × 1080 @30fps. Max bitrate 60 Mbps (H.264) or 40 Mbps (H.265). Shared between the Matrice 4D and 4TD |
| Laser rangefinder | 1800 m normal-incidence range at 1 Hz, 20% target reflectivity; 600 m oblique-incidence range at 1 Hz; 1 m blind zone. Accuracy: 1 to 3 m, system error under 0.3 m and random error under 0.1 m at 1σ; beyond 3 m, ±(0.2 + 0.0015 × D) m, D in meters. DJI: performance may degrade in rain or fog. Matches the figures published for the Matrice 4T |
| Laser and NIR eye safety | DJI: "DO NOT look directly at the laser range finder or the NIR auxiliary light when the aircraft is powered on." |
| NIR auxiliary light | 5.7° ± 0.3° field of view. DJI: only available with the Matrice 4TD, for lighting the tele camera at night. Matches the Matrice 4T's NIR light |
| Obstacle sensing | Omnidirectional binocular vision system, supplemented by a 3D infrared sensor at the aircraft's underside. Forward and backward measurement range 0.5 to 20 m; lateral and downward 0.5 to 16 m. Requires adequately lit, texture-rich surfaces to function |
Ingress protection, weather and what voids it
| Ingress protection rating | IP55, DJI's own term for both the Matrice 4TD and Matrice 4D. Tested under controlled laboratory conditions. DJI states the rating is not permanently effective and may decrease with product wear and tear. The Matrice 4T carries No Standard Protection Level, DJI's own term, by comparison |
| What voids the rating | DJI's pre-flight checklist: "Make sure the covers of all the ports have been closed properly if not used. Otherwise, the ingress protection performance will be affected." An open, uncovered port is DJI's own stated failure mode |
| Water exposure with power on | DJI: "DO NOT power on the aircraft when water is inside the aircraft or its components. Otherwise, it may cause permanent component damage." An IP55 rating does not remove this caution |
| Flight condition requirements | DJI: the aircraft is designed to operate in good to moderate weather. DO NOT use it in severe weather including wind speeds exceeding 12 m/s, snow, moderate rain, fog, hail, or lightning |
| Sand and dust | DJI: to avoid affecting flight performance and motor service life, DO NOT take off or land on sandy or dusty surfaces |
| Third-party payload sealing | DJI: a third-party payload's protection rating should be equal to or higher than that of the aircraft, and its ports should be properly sealed. If any seal fails and water leaks into the aircraft, DJI states it will seriously affect flight safety |
| Dock 3's own rating | DJI Dock 3 is IP56 rated, one step above the aircraft's IP55, and carries the same laboratory-conditions and wear-and-tear caveats |
Battery and charging
| Battery model | DJI Matrice 4D Series Battery, model BPX230-6768-22.14: 6768 mAh, 22.14 V standard voltage, 25.5 V max charging voltage, Li-ion 6S, LiNiMnCoO2 chemistry, 149.9 Wh, 640 g, rated for 400 cycles |
| Low-temperature charging | Supports low-temperature self-heating charging. The Matrice 4T's battery does not support this |
| Charging temperature | 5 °C to 45 °C (41 °F to 113 °F), confirmed identically in both the specs table and the battery product-information leaflet. DJI's ideal charging range for battery longevity is 22 °C to 28 °C (72 °F to 82 °F) |
| Charging method and hub | Charges via a dedicated DJI Matrice 4D Series 240 W Charging Hub, a different, more powerful hub than the Matrice 4T/4E's 100 W hub. The hub charges three batteries in sequence, supporting Standard Mode (100% SOC) and Ready-to-Fly Mode (90% SOC) |
| Recharge interval via Dock 3 | 27 minutes to charge the aircraft's battery from 15% to 95% at 25 °C, so 27 minutes is DJI's stated minimum interval between two dock-launched operations. The dock does not automatically swap the aircraft's battery |
| Post-flight charging caution | DJI: DO NOT charge the battery immediately after flight; its temperature may be too high and cause serious battery damage. Allow it to cool to near room temperature first |
| Battery handling cautions | DJI: DO NOT use swollen, leaking or damaged batteries; DO NOT disassemble or pierce a battery; DO NOT use non-DJI batteries or chargers; DO NOT leave a battery covered in moisture or drop it in water; keep batteries away from children |
| Battery temperature and combustion risk | DJI: batteries should be used at the specified temperature range. A high temperature can cause an explosion or fire; a low temperature will reduce battery performance |
Dock 3 and standalone use
| Manual flight without the dock | DJI's FAQ: "Do the DJI Matrice 4D Series drones support manual flight with a remote controller? Yes, they can link with DJI RC Plus 2 Enterprise for manual flight." DJI also publishes a dedicated user manual for RC Plus 2 (standalone) operation, separate from its Dock 3 manual |
| Dual controller support | Not supported. DJI: the Matrice 4D Series does not support simultaneous use with two remote controllers |
| Controller compatibility across the family | DJI's controller specification table lists the DJI RC Plus 2 Enterprise as supporting Matrice 4TD/4D and Matrice 4T/4E. The same controller purchased for a Matrice 4T also flies a Matrice 4TD |
| Live view quality | 720p/30fps or 1080p/30fps with DJI RC Plus 2 Enterprise (standalone). 540p/30fps, 720p/30fps or 1080p/30fps with DJI Dock 3 and DJI FlightHub 2 |
| Activation requirement | DJI: the Matrice 4D/4TD must be activated via the DJI Pilot 2 app or the DJI Enterprise app before use, regardless of dock or standalone operation |
Mapping, software and region
| Precision mapping with RTK | DJI: the Matrice 4D supports precise mapping after enabling the RTK function. Equipping the Matrice 4TD with the RTK module cannot guarantee the final precision. Same split as the Matrice 4T (no guarantee) versus the Matrice 4E (supported) |
| Mapping without ground control points | DJI: only the 4/3 CMOS wide-angle camera on the Matrice 4D supports mapping without GCPs. The Matrice 4TD's cameras are not stated to support this |
| SDKs | DJI Matrice 4D Series supports Payload SDK, Mobile SDK and Cloud API. DJI directs developer queries to dev@dji.com |
| Cloud platform | DJI FlightHub 2, FlightHub 2 On-Premises Version, FlightHub 2 FlightHub Sync, DJI Cloud API |
| Cross-border use | DJI: "Can I use the DJI Matrice 4D Series across countries or regions? No. Please confirm the applicable countries and regions with your dealer before purchasing." |
| Certification | C2 and C6 certified by the European Union Aviation Safety Agency (EASA) |
| Warranty and care coverage | DJI's own footnote states that coverage varies by country and region. Call +1 888 850 6533 and we will confirm what your order includes |
Ordering
| Dealer status | Authorized DJI Enterprise dealer |
| Purchase orders | Accepted from universities, colleges and government agencies |
| Shipping | Shipped direct from the manufacturer |
| Speak to us | +1 888 850 6533, Monday to Friday, 9 to 5 Mountain Time |
