DJI Matrice 4D Drone
W-9 and vendor pack with every quote
Shipped direct from the manufacturer
IP55 where the Matrice 4E carries no ingress rating at all, a -20°C to 50°C operating range, and a self heating 6S battery. The cameras are identical, and the arms do not fold.
01
The Matrice 4D is the Matrice 4E with a weather rating, and that is the whole argument
DJI rates this aircraft IP55. It rates the Matrice 4E and 4T at No Standard Protection Level, its term for no ingress rating at all. Ingress protection is resistance to dust and water. The 4D operates from -20°C to 50°C (-4°F to 122°F), where the 4E stops at -10°C to 40°C. Its battery is a different product: 6S lithium ion, 149.9 Wh, 400 rated cycles, and it self heats to charge in the cold. The 4E and 4T share a 4S pack at 99.5 Wh and 200 cycles, with no self heating. The packs are not interchangeable. Flight time is 54 minutes, measured flying forward at a constant 12 m/s in a windless laboratory, obstacle avoidance off. DJI's marketing page states 47 minutes at 15 m/s, which its own specification page does not support. Treat that figure as contested.
What the mapping-focused half of the Dock 3 pair is for
DJI Enterprise's own case study of Dock 3 in daily, uncrewed survey use.
02
The cameras are identical to the 4E's, so this buys weather and not better imagery
DJI says the drones use the same cameras as the Matrice 4 Series. The 4D has a 4/3 inch CMOS wide angle camera at 20 MP effective, plus 48 MP medium tele and tele cameras. CMOS is the chip that catches the light, and MP is megapixels. Those are the Matrice 4E's sensors exactly, mechanical shutter included. Neither has a thermal camera or a near infrared lamp. On DJI's Dock 3 page both sit under the Matrice 4TD heading; on its Matrice 4 Series page, under the 4T. Both DJI specification pages put the shared laser rangefinder's accuracy beyond 3 m at +/-(0.2+0.0015 x D), D in meters. Nothing on this aircraft is a better survey camera than the 4E's.
03
IP55 is a laboratory rating with conditions, and DJI lists what voids it
IP55 comes from IEC 60529, the international ingress standard. DJI tested it in stable laboratory conditions with the Intelligent Flight Battery fitted, and says the rating is not permanent and may lower over an extended period. Its user manual lists what voids it. An unofficial or loosely installed battery, expansion port covers left open, a loose dongle compartment or external device, a cracked shell, aged water resistant adhesive. DJI also says do not fly when rainfall exceeds 100 mm in 24 hours, and that the warranty does not cover water damage. The anti icing propellers lose effectiveness with use, and DJI says replace them at least every 12 months or 500 flight hours. Charging is on a 240 W hub, three packs in sequence. One dealer page states a wider operating temperature; we use DJI's. DJI's safety guidelines go further than the rating. The aircraft is designed for good to moderate weather. DJI says not to fly it in winds over 12 m/s, snow, moderate rain, fog, hail or lightning.
04
The arms do not fold, and a crew moving between sites daily should buy the 4E instead
DJI's FAQ says the arms of the Matrice 4D Series do not fold. DJI publishes a single dimension figure of 377.7 by 416.2 by 212.5 mm without propellers. The Matrice 4E folds. For a survey team moving between sites in a vehicle, that is a real cost in case size, van space and handling. If your crew runs three sites a day in dry conditions, buy the 4E. Choose the 4D when the season is wet or cold, or when the aircraft lives at one site. It weighs 1850 g with battery, propellers and a microSD card. DJI says the 4D supports greater payload capacity than the 4E and 4T. It publishes no gram figure anywhere we checked, and we will not invent one.
05
DJI Dock 3 is optional, and the RC Plus 2 Enterprise controller flies this aircraft on its own
DJI publishes the Matrice 4D under its Dock 3 pages, which misleads people. You do not need a dock. DJI's FAQ answers it directly: the 4D Series links with the DJI RC Plus 2 Enterprise controller for manual flight. DJI publishes a separate user manual for that configuration. It is the same controller the 4E and 4T use. The reverse does not hold. DJI states Dock 3 supports only the Matrice 4D Series, so a 4E or 4T owner cannot dock at all. Airborne relay, one aircraft flying high to relay signal for another, works in standalone flight; docked, DJI says currently no. Dock 3 is a separate purchase; call us for current availability.
06
DJI says it maps precisely with RTK, and publishes no accuracy figure to go with it
RTK is a live satellite correction on top of GPS, and the module is built into the aircraft. DJI's FAQ says the 4D supports precise mapping after enabling RTK. Only its 4/3 wide angle camera maps without ground control points, the surveyed marks placed on the ground. DJI publishes no accuracy figure for the finished map, in centimeters or percent, anywhere we checked. It does not restate an RTK positioning accuracy on this aircraft's own specification page either, so we are not carrying the 4E's figure across. Five direction oblique capture is here as it is on the 4E, and DJI's own footnote says the function is currently insufficient for urban area mapping.
07 FOR UNIVERSITIES, COLLEGES AND GOVERNMENT AGENCIES
How to buy it, and what we will not print until DJI confirms it
My Surveying Direct is an authorized DJI Enterprise dealer, and the aircraft is shipped direct from the manufacturer. We accept purchase orders from universities, colleges and government agencies. The 4D Series is C2 and C6 certified by the European Union Aviation Safety Agency; the 4E and 4T are C2 only. C6 needs an FTS flight termination module, which DJI includes in some regions only. Unconfirmed for units sold here. Also unconfirmed: the free DJI Care Enterprise Plus or warranty year, which DJI varies by country, any bundled software, and what ships in your box. DJI publishes no guaranteed software update date for this product anywhere we checked. DJI says the 4D Series may not be used across countries or regions. Call +1 888 850 6533, Monday to Friday, 9 to 5 Mountain Time.
Checkout above. Financing available with Affirm.
Institutions only: universities, colleges and government agencies.
Attached automatically.
Send the certificate once, we hold it on file.
On request, for committee approval.
One person, from quote to delivery.
REFERENCE
Specifications
Cameras
| Wide-angle camera | 4/3-inch CMOS, 20 MP effective pixels, f/2.8-f/11, 24 mm equivalent focal length, FOV 84 degrees, focus 1 m to infinity. Matches the Matrice 4E's wide camera spec row for row; DJI's Dock 3 product page states it directly: the drones use the same cameras as the Matrice 4 Series |
| Wide-angle camera shutter | Electronic Shutter 2-1/8000 s; Mechanical Shutter 2-1/2000 s |
| Wide-angle camera max photo size | 5280 x 3956 (20 MP) |
| Wide-angle camera photo format | JPEG/DNG (RAW) |
| Wide-angle camera ISO | Normal Mode: 100-25600. Night Scene Mode: 100-204800, the same ceiling the Matrice 4E publishes for its wide camera |
| Wide-angle camera panorama mode | 20 MP raw image; 100 MP stitched image. The Matrice 4E's wide camera publishes the same mode |
| Medium tele camera | 1/1.3-inch CMOS, 48 MP effective pixels, f/2.8, 70 mm equivalent focal length, FOV 35 degrees, focus 3 m to infinity. Shared spec across the whole Matrice 4 family (4D, 4TD, 4E, 4T) |
| Tele camera | 1/1.5-inch CMOS, 48 MP effective pixels, f/2.8, 168 mm equivalent focal length, FOV 15 degrees, focus 3 m to infinity, 16x digital zoom (112x hybrid zoom). Shared spec across the whole Matrice 4 family |
| Medium tele and tele max photo size | Medium tele 8064 x 6048; tele 8192 x 6144 |
| Medium tele and tele ISO, Night Scene | 100 to 409600 on both cameras |
| Minimum photo interval | 0.5 s (the Matrice 4TD's is 0.7 s) |
| Laser rangefinder | Normal incidence range 1800 m (1 Hz) at 20% target reflectivity; oblique incidence range 600 m (1 Hz); blind zone 1 m. Accuracy at 1-3 m: system error under 0.3 m, random error under 0.1 m at 1 sigma. Beyond 3 m: +/-(0.2+0.0015 x D), D in meters. DJI notes performance may degrade in rain or fog. Shared spec with the Matrice 4TD, 4E and 4T |
| Lens defogging | Wide-angle, medium tele and tele cameras all support lens defogging |
What the 4D does not have
| Thermal camera | None. DJI's Image Sensor table lists the 4D's three cameras (wide, medium tele, tele) with no thermal entry. DJI puts the thermal camera under the Matrice 4TD on its Dock 3 page, and under the 4T on its Matrice 4 Series page |
| NIR auxiliary light | None. DJI labels the Infrared Illumination row "DJI Matrice 4TD:" on its Dock 3 page, and puts the same lamp under the 4T on its Matrice 4 Series page |
Mapping and precision
| Mapping without ground control points | DJI's FAQ: "Only the 4/3 CMOS wide-angle camera on DJI Matrice 4D supports mapping without GCPs" |
| Precision mapping with RTK | DJI's FAQ: "DJI Matrice 4D supports precise mapping after enabling the RTK function." DJI publishes no absolute processed mapping-accuracy percentage or centimeter figure beyond the RTK positioning accuracy row below |
| 5-direction smart oblique capture | DJI: the Matrice 4D "excels in high-precision mapping, offering a new 5-direction oblique photography function, 3-direction orthophoto photography, and real-time terrain following." DJI publishes the same 5-direction capture for the Matrice 4 Series. DJI's own footnote on this feature: "The current functionality is insufficient to meet the needs of urban area mapping. Future updates will continue to optimize flight routes and mapping solutions for urban areas" |
Aircraft and flight performance
| Weight | 1850 g, including the battery, propellers and a microSD card, but not third-party payloads. Actual weight may vary due to differences in batch materials |
| Max takeoff weight | 2090 g |
| Dimensions | 377.7 x 416.2 x 212.5 mm (L x W x H, without propellers). DJI's FAQ states the Matrice 4D Series' arms are not foldable, unlike the Matrice 4E/4T, which fold; DJI gives no separate folded/unfolded figure for this reason |
| Payload | DJI's FAQ states the Matrice 4D "supports greater payload capacity" than the Matrice 4E/4T, with no gram figure published. The gap between the 1850 g aircraft weight and the 2090 g max takeoff weight is 240 g, but DJI does not label this a payload spec |
| Max ascent speed | 6 m/s (Normal Mode), 10 m/s (Sport Mode) |
| Max descent speed | 6 m/s (Normal Mode), 8 m/s (Sport Mode) |
| Max horizontal speed | At sea level, no wind. Normal Mode with obstacle sensing enabled: 15 m/s forward, 12 m/s backward, 10 m/s sideways. Sport Mode: 21 m/s forward, 19 m/s backward, 15 m/s sideways. When used with DJI Dock, only Normal Mode is supported |
| Max wind speed resistance | 12 m/s, during operation and during takeoff/landing alike |
| Max takeoff altitude | 6500 m |
| Operating temperature | -20°C to 50°C (-4°F to 122°F). Wider than the Matrice 4E/4T's -10°C to 40°C. Confirmed identically on the specs page and inside DJI's own Dock 3 + Matrice 4D User Manual |
| Max flight time | 54 minutes, measured flying forward at a constant 12 m/s in a windless laboratory environment at 20 m above sea level, in photo mode with no photo-taking operation, obstacle avoidance off, from 100% to 0% battery |
| Max hovering time | 47 minutes, measured hovering in a windless environment at 20 m above sea level, from 100% to 0% battery |
| Max operating radius | 10 km, measured at approximately 25 C with a safe battery level of 15%, windless, round-trip flight speed of approximately 15 m/s, and includes an 18-minute hovering reserve |
| Max flight distance | 43 km, measured at a constant 16 m/s in a windless environment at 20 m above sea level, from 100% to 0% battery |
Positioning and RTK
| GNSS | GPS + BeiDou + Galileo + QZSS + GLONASS. QZSS and GLONASS are supported only when the RTK module is enabled |
| Hovering accuracy | Windless or breezy conditions. Vertical: +/-0.1 m (vision positioning), +/-0.5 m (GNSS), +/-0.1 m (RTK). Horizontal: +/-0.3 m (vision positioning), +/-0.5 m (GNSS), +/-0.1 m (RTK) |
| RTK positioning accuracy | Not itemized separately on the Matrice 4D's own aircraft spec block on the Dock 3 specs page; the RTK Fix figure of 1 cm + 1 ppm horizontal / 1.5 cm + 1 ppm vertical is DJI's published figure for the Matrice 4E/4T's identical RTK subsystem and is not re-stated on the Dock 3 page, so it is not carried over here without a same-page confirmation |
| RTK module | Integrated on the aircraft |
| Beacon | Integrated on the aircraft. DJI's safety guidelines: "DO NOT point the beacon directly into eyes to avoid injury" |
Battery and charging
| Model and chemistry | DJI Matrice 4D Series Battery: 6768 mAh, 22.14 V, Li-ion 6S, LiNiMnCoO2 chemistry, 149.9 Wh, 640 g. A different product to the Matrice 4E/4T's shared battery (6741 mAh, 14.76 V, Li-ion 4S, 99.5 Wh, 401 g); not interchangeable |
| Max charging voltage | 25.5 V |
| Cycle count | Rated for 400 cycles. DJI's safety guidelines: stability is affected after the rated cycle count and the buyer is responsible for device damage and third-party losses from a battery used past its rated cycles. Double the Matrice 4E/4T's 200-cycle rating |
| Discharge and charge rate | Discharge rate 4C; max charging power 1.8C |
| Operating temperature | -20°C to 45°C (-4°F to 113°F). DJI's FAQ: battery life is shortened in low-temperature environments; schedule flight time accordingly |
| Charging temperature | 5°C to 45°C (41°F to 113°F) |
| Low-temperature self-heating | Supported. The Matrice 4E/4T's battery explicitly does not support self-heating |
| Charging with the 240 W Charging Hub | DJI's FAQ: Standard Mode takes approximately 40 minutes to fully charge one battery from 15%. Ready-to-Fly Mode takes approximately 30 minutes to charge one battery from 15% to 90% |
| Charging with DJI Dock 3 | DJI's FAQ: Standard Mode takes approximately 37 minutes to fully charge one battery from 15%. Ready-to-Fly Mode takes approximately 27 minutes to charge one battery from 15% to 95%, a different reserve percentage than the same mode via the standalone hub |
| Charging hub | DJI Matrice 4D Series 240W Charging Hub. Charges up to three batteries in sequence. DJI's FAQ: cannot be charged using other USB-C chargers |
| Charging while mounted | DJI's FAQ: the battery cannot be charged while mounted on the aircraft |
| Storage and over-discharge caution | DJI's safety guidelines: "DO NOT store the battery for an extended period after fully discharging. Otherwise, the battery may over-discharge and cause irreparable damage to the battery cell." A battery stored for an extended period at a low level enters deep hibernation and must be recharged to bring it out |
Ingress protection, weather and honesty notes
| Ingress protection rating | IP55, per IEC 60529, achieved under stable laboratory conditions when the aircraft is equipped with its Intelligent Flight Battery. DJI: "The protection rating is not permanent and may lower over an extended period" |
| What voids the IP55 rating | Per DJI's User Manual: batteries other than the official battery are used; the battery is not firmly installed; expansion port covers are not firmly closed when not in use; the cellular dongle compartment or an external device (speaker, spotlight) is not firmly installed or its screws are not tightened; the aircraft shell is cracked or its water-resistant adhesive is aged or damaged. DJI also states: "DO NOT fly when the amount of rainfall exceeds 100 mm/24 h," and that the product warranty does not cover water damage |
| Cosmetic note | DJI: body surface discoloration after long-term use does not affect performance or the IP rating |
| Anti-ice propeller maintenance | DJI's FAQ: anti-icing effectiveness decreases with use; replace propellers at least every 12 months or after 500 flight hours. Do not use oil- or alcohol-based solvents on them, which can damage the anti-icing layer |
| Laser and beacon eye safety | DJI's safety guidelines: "DO NOT look directly at the laser range finder or the NIR auxiliary light when the aircraft is powered on" and "DO NOT point the beacon directly into eyes to avoid injury." The 4D has no NIR light of its own; this caution is shared family-wide safety-document text |
| Genuine parts caution | DJI's safety guidelines: use only genuine DJI parts or DJI-authorized parts; unauthorized parts may cause system malfunctions and compromise flight safety |
| Regional use restriction | DJI's FAQ: "Can I use the DJI Matrice 4D Series across countries or regions? No. Please confirm the applicable countries and regions with your dealer before purchasing" |
Controller
| Standard controller | DJI RC Plus 2 Enterprise. DJI's specs page confirms it: "Supports Matrice 4TD/4D, Matrice 4T/4E," the same controller across the entire Matrice 4 family |
| Screen | 7.02-inch, 1920 x 1200, 1400 nits, 60 fps, 10-point multi-touch |
| Controller battery | Built-in 2S2P 18650 Li-ion, 6500 mAh at 7.2 V, 46.8 Wh. Optional external WB37 battery adds 4920 mAh at 7.6 V, 37 Wh |
| Controller operating temperature | -20°C to 50°C (-4°F to 122°F) |
| Weight | 1.15 kg without external battery |
| Storage | RAM 8 GB plus ROM 128 GB UFS, expandable via microSD card |
| Dual controller support | Not supported. DJI's FAQ: "Do the DJI Matrice 4D Series drones support simultaneous use with dual remote controllers? No" |
| DJI Goggles compatibility | Not compatible, per DJI's FAQ |
| Third-party USB-C charging | DJI's FAQ: other USB-C chargers can charge the controller; a 100 W+ charger supporting the PD protocol is recommended for full charging speed |
Video transmission
| System | DJI O4+ Enterprise. The Matrice 4E/4T's own specs pages record plain "O4 Enterprise" for those aircraft; a real naming divergence |
| Antenna | 8 antennas, 2T4R |
| Max transmission distance, unobstructed | 25 km (FCC), 12 km (CE/SRRC/MIC), measured free of interference. The above figures show the farthest range for one-way, non-return flights under each standard |
| Max transmission distance, with interference | Strong interference (dense buildings, residential areas): 1.5-5 km. Medium interference (suburban areas, city parks): 5-15 km. Weak interference (open spaces, remote areas): 15-25 km. Tested under the FCC standard; provides no guarantee as to actual flight distance |
| Live view quality | 720p/30fps or 1080p/30fps with DJI RC Plus 2 Enterprise (standalone). 540p/30fps, 720p/30fps or 1080p/30fps with DJI Dock 3 and DJI FlightHub 2 (docked) |
| Max download speed | 20 MB/s with DJI Dock 3; 20 MB/s with DJI RC Plus 2 Enterprise |
| Latency | Aircraft-to-dock video transmission latency is approximately 100 milliseconds, affected by actual environmental conditions |
| 4G transmission | Not standard. DJI's FAQ: the Matrice 4D Series does not come standard with a DJI Cellular Dongle 2, sold separately and not available in all countries or regions |
Dock 3 compatibility, the central question
| Standalone operation | DJI: the Matrice 4D "can pair with DJI RC Plus 2 Enterprise for standalone use." DJI's FAQ confirms directly: "Do the DJI Matrice 4D Series drones support manual flight with a remote controller? Yes, they can link with DJI RC Plus 2 Enterprise for manual flight." DJI publishes a second, separate user manual dedicated to this configuration, with no dock involved at all |
| Does the 4D require Dock 3 | No. It is bought and flown manually with the RC Plus 2 controller alone, exactly like the Matrice 4E/4T. Dock 3 is a separate, optional purchase for automated, uncrewed operation |
| Does Dock 3 require the 4D | Yes, exclusively. DJI's FAQ: "Which drones does DJI Dock 3 support? DJI Dock 3 only supports the DJI Matrice 4D Series drones." Dock 3 will not fly a Matrice 4E, 4T, or any other DJI aircraft |
| Airborne relay and Dock 3 | Airborne relay (one drone flying high as a relay for another) is a standalone, RC Plus 2 only capability. DJI's FAQ: "Do the DJI Matrice 4D Series drones support airborne relay when connected with DJI Dock 3? Currently no" |
| Dock 3's own ingress and operating range | DJI Dock 3 itself is rated IP56 (higher than the aircraft's IP55) and operates from -30°C to 50°C (-22°F to 122°F), a wider range than the aircraft's own -20°C to 50°C |
| Dock 3 to aircraft ratio | DJI's FAQ: one aircraft can use multiple docks (multi-dock task); one dock cannot serve multiple aircraft |
Regulatory and warranty
| EASA certification | C2 and C6 certified by the European Union Aviation Safety Agency. The Matrice 4E/4T are C2 certified only; the Matrice 4D Series adds C6 |
| FTS module and C6 | DJI's Quick Start Guide: an FTS (flight termination system) module is required to meet C6 certification requirements and is included standard in some regions only. Unconfirmed whether it is included for US retail sales through our channel |
| Warranty / care offer | DJI: buyers of the Matrice 4D/4TD Series get 1 year of DJI Care Enterprise Plus or 1 year of Official Extended Warranty Service free with purchase, but DJI's own footnote states the plan offered varies by country or region; unconfirmed for US retail sales through our channel |
