FJD Trion Model Forest Module
W-9 and vendor pack with every quote
Shipped direct from the manufacturer
An add-on to FJD Trion Model that segments and analyzes trees from scanned point cloud data, documented by FJD around the Trion S1 scanner specifically.
01
FJD documents this module around the Trion S1 scanner, and does not state whether it works the same way on other Trion scanners' data
FJD's own manual introduces this chapter around the combined use of the Trion S1 laser scanner and Trion Model software. It does not say whether point clouds from the P1, P2 or S2 work the same way in this module. If your scans come from a different Trion scanner, call first and we will help you confirm fit.
02
It segments a scanned point cloud tree by tree, then measures height, crown width and standing volume
The module first extracts ground points from the forestry scene, which the manual describes as critical for the segmentation step that follows. It then segments the point cloud tree by tree, and lets you add, merge or delete individual trees in the result. From there it removes the scanner operator's own support pole from the data, analyzes crown width, calculates standing timber volume by species, runs a separate carbon-storage calculation, and identifies tree species from panoramic imagery. Output is a single-tree distribution map and a batch report.
03
It is a paid add-on to the base Trion Model license, not a standalone program
This module requires a base Trion Model license and is not sold or usable on its own. FJD sells it as a 1-year or a permanent license, each at its own separate price, activated with a code entered in the software after purchase. If the license expires, FJD's own instruction is to contact its technical support.
04 FOR UNIVERSITIES, COLLEGES AND GOVERNMENT AGENCIES
We take purchase orders from universities, colleges and government agencies, with a W-9 on every quote
My Surveying Direct is an authorized FJ Dynamics reseller. Every purchase order quote includes a W-9 and our vendor pack. The license is delivered electronically, with nothing to ship. Call and we will confirm this module fits your scanner and your forestry workflow before you buy it. Call +1 888 850 6533, Monday to Friday, 9 am to 5 pm Mountain Time.
Checkout above. Financing available with Affirm.
Institutions only: universities, colleges and government agencies.
Attached automatically.
Send the certificate once, we hold it on file.
On request, for committee approval.
One person, from quote to delivery.
REFERENCE
Specifications
What it is
| Function | An add-on module for FJD Trion Model that adds forestry survey tools to point cloud data already captured by an FJD Trion scanner. It requires a base Trion Model license and is not a standalone application |
| Named scanner pairing | FJD's own manual introduces this chapter specifically around 'the combined use of the FJD Trion S1 3D laser scanner and the FJD Trion Model point cloud processing software,' naming the S1 rather than the P1, P2 or S2. My Surveying Direct's catalog does not carry the S1; whether the module works equally on point clouds from the P1, P2 or S2 was not stated by FJD anywhere checked and is not asserted here |
| Marketing description | 'Edit segmentation results to extract tree location, height, and crown width, and batch-extract attributes to create reports that provide valuable forest survey, management, and planning insights' |
What it does, per the manual's own chapter
| Pre-processing | Extracts ground points from the forestry scene point cloud, described as critical for the tree-by-tree segmentation step that follows |
| Segmentation and tree editing | Segments the point cloud tree by tree, then allows the operator to add, merge or delete individual trees in the segmentation result |
| Calculation and analysis | Support pole removal (to exclude the scanner operator's own support pole from the result), crown analysis, per-tree property calculation, standing timber storage-capacity (volume) calculation by species, a carbon-storage calculation, and tree species identification from panoramic imagery |
| Output | A single-tree distribution map and a batch report, drawn from the segmented and analyzed data |
| Species identification caution | The manual notes that if the species-identification configuration file is not loaded, a warning pop-up appears prompting the user, which is the only caution named in this chapter; it is a software prompt, not a physical safety warning |
Licensing
| Requires | A base Trion Model license; this module is not sold or usable on its own |
| Terms | Sold as a 1-year or a permanent license, each at its own separate price |
| Activation | Applied for as an activation code at purchase and entered in the software's license setting window; FJD's instruction on expiry is to contact FJDynamics technical support |
| Delivery | Electronic. No physical shipment |
Ordering
| Dealer status | Authorized reseller |
| Purchase orders | Accepted, with a W-9 and vendor pack included with every quote |
| Speak to us | +1 888 850 6533, Monday to Friday, 9 am to 5 pm Mountain Time |
