FJD Trion Model Drawing Module
W-9 and vendor pack with every quote
Shipped direct from the manufacturer
An add-on to FJD Trion Model that turns scanned point cloud data into 2D vector drawings, with point-cloud-slice and panoramic-image assisted tracing.
01
It converts scanned point cloud data into 2D vector drawings, using point cloud slices and panoramic images as a guide
Selecting a point cloud or vector file and activating the drawing feature opens FJD's 2D vector drawing mode. Vector drawing is assisted by point cloud slices and by panoramic images, in .mp4, .avi or .insv format. The point cloud can be rotated, panned and zoomed; clicking a start and end point creates a sliced plane, with adjustable position and thickness, to draw against. Contour lines extract directly from the point cloud as an alternative to manual tracing.
02
Drawing primitives, editing tools and measurement, the same category of tools found in general CAD software
Point, straight line, polyline, arc, rectangle, circle, ellipse and polygon primitives are available, alongside editing tools including extend, copy, trim, intersect, rotate, mirror and offset. Coordinates, length, angle and area measurement tools work inside the drawing workspace. Drawing settings cover reference points, dimension settings, polar tracking, object snap and orthographic drawing.
03
It is a paid add-on to the base Trion Model license, not a standalone program
This module requires a base Trion Model license and is not sold or usable on its own. FJD sells it as a 1-year or a permanent license, each at its own separate price, and the SKU is identical whether bought on its own product page or as a module on the base software listing. Activation happens through a code applied for at purchase and entered in the software. If a license expires, FJD's own instruction is to contact its technical support.
04 FOR UNIVERSITIES, COLLEGES AND GOVERNMENT AGENCIES
We take purchase orders from universities, colleges and government agencies, with a W-9 on every quote
My Surveying Direct is an authorized FJ Dynamics reseller. Every purchase order quote includes a W-9 and our vendor pack. The license is delivered electronically, with nothing to ship. Call and we will confirm this module fits your workflow before you buy it. Call +1 888 850 6533, Monday to Friday, 9 am to 5 pm Mountain Time.
Checkout above. Financing available with Affirm.
Institutions only: universities, colleges and government agencies.
Attached automatically.
Send the certificate once, we hold it on file.
On request, for committee approval.
One person, from quote to delivery.
REFERENCE
Specifications
What it is
| Function | An add-on module for FJD Trion Model that converts point cloud data into 2D vector drawings. It requires a base Trion Model license and is not a standalone application |
| Marketing description | FJD's own standalone product page for this module lists: 2D slicing and clipping, vector drawing and editing, automatic contour extraction, layer and drawing management, dimensions and annotations, and CAD export |
What it does, per the manual's own chapter
| Entering drawing mode | Selecting a point cloud or vector file and activating the drawing feature opens 2D vector drawing mode |
| Assisted drawing | Vector drawing is assisted by point cloud slices and by panoramic images (supported formats: .mp4, .avi, .insv). The point cloud can be rotated, panned and zoomed; clicking a start and end point creates a sliced plane from the point cloud, with adjustable position and thickness, to draw against |
| Contour extraction | Extracts contour lines directly from point cloud data as an alternative to manual tracing |
| Drawing tools | Point, straight line, polyline, arc, rectangle, circle, ellipse and polygon primitives, with editing tools including extend, copy, trim, intersect, rotate, mirror and offset |
| Measurement | Coordinates, length, angle and area measurement tools inside the drawing workspace |
| Drawing settings | Set reference, dimension settings, polar tracking, object snap and orthographic drawing, the same category of assists found in general CAD drafting tools |
Licensing
| Requires | A base Trion Model license; this module is not sold or usable on its own |
| Terms | Sold as a 1-year or a permanent license, each at its own separate price. This module's SKU is identical whether bought from its standalone product page or as a variant of the base Trion Model Software listing, confirmed by matching SKU numbers across both of FJD's own pages |
| Activation | Applied for as an activation code at purchase and entered in the software's license setting window; FJD's instruction on expiry is to contact FJDynamics technical support |
| Delivery | Electronic. No physical shipment |
Ordering
| Dealer status | Authorized reseller |
| Purchase orders | Accepted, with a W-9 and vendor pack included with every quote |
| Speak to us | +1 888 850 6533, Monday to Friday, 9 am to 5 pm Mountain Time |
